The 700G Series models can measure -14 to 15 pounds-per-square-inch (psi) with a resolution of 0.001 psi (model 700G04) to -14 to 10,000 psi with a 1 psi resolution (model 700G31) with a 0.05% total measurement uncertainty for one year, providing pressure testing for a wide range of applications. They can log up to 8,493 pressure measurements to memory when used in conjunction with 700G/TRACK software . The pressure gauges have an Intrinsically Safe rating of CSA: Class1, Div 2, Groups A-D and ATEX: II 3 G Ex nA IIB T6 for work in areas classified to include explosive gasses. Fluke's 700G Series offers two optional test kits. The 700PTPK Pneumatic Test Kit and 700HTPK Hydraulic Test Kit include hand pumps, hoses and adapters, and can be combined with any 700G Series gauge to create complete, portable test systems. Both kits include a hard case to protect the pump and gauge while allowing the gauge to remain connected to the pump. For users who need to record and analyse pressure measurements over time, Fluke 700G/TRACK logging software allows logging data to be downloaded to a PC. With 700G/TRACK, logging configurations can be downloaded to 700G Series gauges for remote logging events. Those measurements can then be uploaded and displayed on a PC, or exported for further analysis.
